Cisco Intel Xeon Silver 4510 processor 2.4 GHz 30 MB
- Intel Xeon Silver 4510 2.4 GHz
- 30 MB FCLGA4677
- Processor cores: 12 64-bit 150 W
- Maximum internal memory supported by processor: 4 TB DDR5-SDRAM
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Processor codename | Sapphire Rapids |
| Thermal Design Power (TDP) | 150 W |
| Processor cache | 30 MB |
| Processor boost frequency | 4.1 GHz |
| Processor operating modes | 64-bit |
| Intel® UPI Speed | 16 GT/s |
| Processor threads | 24 |
| Processor series | Intel Xeon Silver 4000 Series |
| Box | No |
| Processor socket | FCLGA4677 |
| Processor cores | 12 |
| Processor base frequency | 2.4 GHz |
| Processor model | 4510 |
| Processor generation | Intel Xeon Scalable 5th Gen |
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Octa-channel |
| Memory clock speeds supported by processor | 4400 MHz |
| Memory types supported by processor | DDR5-SDRAM |
| Maximum internal memory supported by processor | 4 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 2S |
| Embedded options available | Yes |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 80 |
| Use conditions | Server/Enterprise |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® In-memory Analytics Accelerator (IAA) | 1 |
| Intel® Data Streaming Accelerator (DSA) | 1 |
| Intel® On Demand Feature Activation | Yes |
| Intel® Total Memory Encryption – Multi Key | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® OS Guard | Yes |
| Intel® Boot Guard | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 64 GB |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 84 °C |
| DTS Max | 102 °C |
| Technical details | |
|---|---|
| Servicing status | Baseline Servicing |
| Launch date | Q4’23 |
| Status | Launched |
| Package carrier | E1B |
| Weight & dimensions | |
|---|---|
| Processor package size | 77.5 x 56.5 mm |
