Lenovo 4XB7A38240 internal solid state drive 6.4 TB Half-Height/Half-Length (HH/HL) PCI Express 3.0 NVMe TLC 3D NAND
- 6.4 TB Half-Height/Half-Length (HH/HL) PCI Express 3.0
- 718000 IOPS
- 117000 IOPS
- TLC 3D NAND NVMe
- Component for: Server/workstation
The ThinkSystem Kioxia CM5-V Mainstream NVMe Flash Storage Adapters in capacities from 1.6 TB to 6.4 TB are advanced data center PCIe add-in cards optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
This product guide provides essential presales information to understand the Mainstream NVMe adapter offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the adapters and consider their use in IT solutions.
| Features | |
|---|---|
| Certification | Underwriters Laboratories: UL60950-1Canada: CAN/CSA-C22.2 No.60950-1TUV: EN 60950-1BSMI (Taiwan): CNS 13438 (CISPR Pub. 22 Class B): D33003MSIP: KN22, KN24 (CISPR Pub. 22 Class B)Australia/New Zealand: AS/NZS CISPR32:2015 Class BCanada: ICES-003 Issue 6 Class BEMC: EN55022 (2010) Class BEMC: EN55024 (2010)RoHS 2011/65/EU: EN50581 (2012) Category 3 |
| Mean time between failures (MTBF) | 2500000 h |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Random latency – write (up to) | 10 µs |
| Random latency – read (up to) | 106 µs |
| Random write (4KB) | 117000 IOPS |
| Random read (4KB) | 718000 IOPS |
| Component for | Server/workstation |
| Memory type | TLC 3D NAND |
| NVMe | Yes |
| Interface | PCI Express 3.0 |
| SSD form factor | Half-Height/Half-Length (HH/HL) |
| SSD capacity | 6.4 TB |
| Power | |
|---|---|
| Power consumption (max) | 16 W |
| Weight & dimensions | |
|---|---|
| Weight | 220 g |
| Height | 69 mm |
| Depth | 19 mm |
| Width | 168 mm |
| Operational conditions | |
|---|---|
| Maximum operating altitude | 5486 m |
| Maximum non-operating altitude | 12192 m |
| Operating shock | 400 G |
| Operating vibration | 2.17 G |
| Operating relative humidity (H-H) | 5 – 95% |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating temperature (T-T) | 0 – 50 °C |
