Lenovo 4Y37A09724 interface cards/adapter Internal Mini-SAS
- Internal
- Host interface: PCIe
- Output interface: Mini-SAS
- S.M.A.R.T. support
- Purpose: Server
- 12 Gbit/s
- Multicolour
The Lenovo ThinkSystem 440-8e and 440-16e SAS/SATA 12Gb HBAs are high performance PCIe 4.0 host bus adapters for external storage connectivity in ThinkSystem servers. The adapters provide either two or four x4 external mini-SAS HD connectors to provide connectivity to external storage devices such as ThinkSystem DE Series storage and LTO9 tape drives.
This product guide provides essential presales information to understand the ThinkSystem external HBAs and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the HBAs and consider their use in IT solutions.
| Ports & interfaces | |
|---|---|
| Expansion card standard | PCIe 4.0 |
| Expansion card form factor | Low-profile |
| Host interface gender | Male |
| Output interface | Mini-SAS |
| Host interface | PCIe |
| Design | |
|---|---|
| Certification | FCC Part 15 Class A Australia/New Zealand (AS/NZS CISPR 22) Canada (ICES-003 Class B) Europe (EN55022/EN55024) Japan (VCCI V-3) Korea (RRA no 2013-24 & 25) RoHS compliant EN/IEC/UL 60950 Taiwan (CNS 13438) USA (FCC 47 CFR part 15 Subpart B class B) WEEE |
| Purpose | Server |
| Product colour | Multicolour |
| Internal | Yes |
| Features | |
|---|---|
| S.M.A.R.T. support | Yes |
| Data transfer rate (max) | 12 Gbit/s |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Operating relative humidity (H-H) | 20 – 90% |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating temperature (T-T) | 10 – 55 °C |
| System requirements | |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
