Lenovo ThinkSystem SR665 V3 server Rack (2U) AMD EPYC 9274F 4.05 GHz 32 GB DDR5-SDRAM 1800 W
- No OS
- AMD EPYC 9274F (256MB Cache, 4.05GHz)
- 32GB (4800MHz) DDR5-SDRAM (1 x 32)
The Lenovo ThinkSystem SR665 V3 is a 2-socket 2U server that features the AMD EPYC 9004 “Genoa” family of processors. With up to 128 cores per processor and support for the new PCIe 5.0 standard for I/O, the SR665 V3 offers the ultimate in two-socket server performance in a 2U form factor.
This product guide provides essential pre-sales information to understand the ThinkSystem SR665 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR665 V3 and consider its use in IT solutions.
| Processor | |
|---|---|
| Number of processors installed | 1 |
| Processor cache | 256 MB |
| Processor cores | 24 |
| Processor boost frequency | 4.3 GHz |
| Processor frequency | 4.05 GHz |
| Processor model | 9274F |
| Processor family | AMD EPYC |
| Processor manufacturer | AMD |
| Memory | |
|---|---|
| Memory clock speed | 4800 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Design | |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Performance management | XClarity Controller Platinum |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
| Operating system installed | No |
| Power | |
|---|---|
| Power supply | 1800 W |
| Redundant power supply (RPS) support | Yes |
| Operational conditions | |
|---|---|
| Operating altitude | 0 – 3050 m |
| Storage relative humidity (H-H) | 8 – 90% |
| Operating relative humidity (H-H) | 8 – 90% |
| Storage temperature (T-T) | -40 – 60 °C |
| Operating temperature (T-T) | 5 – 45 °C |
| General | |
|---|---|
| Product family | ThinkSystem |
| Weight & dimensions | |
|---|---|
| Depth | 766 mm |
| Height | 87 mm |
| Width | 445 mm |
