Lindy Composite / S-Video to HDMI Converter with Audio
- Easily connect legacy Composite, S-Video and Audio source devices to modern HDMI displays
- Upscales low resolution video to crisp 720 or 1080p
- Supports both PAL and NTSC input devices
- Connects to external audio devices via a 3.5mm audio output
- 2 Year warranty
The Lindy Composite / S-Video to HDMI Converter with Audio is a compact device which allows the connection of legacy analogue AV equipment with modern HDMI displays or projectors.
The converter features a built in up-scaler which enhances low resolution video, providing the option to output both Standard, or High definition HDMI signals, creating a high quality viewing experience, perfect for home office, security, and CCTV applications.
Compatibility is maximised with support for both PAL and NTSC source devices while a low power requirement through USB creates greater flexibility with installation.
Please Note: Audio through the HDMI connection is not supported on HDMI 2.0 displays.
| Features |
| Certification |
CE, FCC, RoHS, REACH |
| Video |
| Analog signal format system |
NTSC, PAL |
| Supported video modes |
576i, 720p, 1080p |
| Ports & interfaces |
| DC-in jack |
Yes |
| Host interface |
Composite + S-Video |
| Output interface |
HDMI + RCA |
| Operational conditions |
| Operating relative humidity (H-H) |
10 – 85% |
| Storage temperature (T-T) |
-10 – 80 °C |
| Operating temperature (T-T) |
0 – 70 °C |
| Weight & dimensions |
| Weight |
84 g |
| Height |
24 mm |
| Depth |
71 mm |
| Width |
113 mm |
| Packaging data |
| Package weight |
294 g |
| Package height |
60 mm |
| Package depth |
145 mm |
| Package width |
190 mm |
| Quantity |
1 |
| Manual |
Yes |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
