Qbic FHD-100 embedded computer 1.6 GHz 8 GB eMMC 2 GB
| Processor | |
|---|---|
| Processor cores | 4 |
| Processor frequency | 1.6 GHz |
| Memory | |
|---|---|
| Internal memory type | DDR3-SDRAM |
| Internal memory | 2 GB |
| Storage | |
|---|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSDHC |
| Storage media | eMMC |
| Total storage capacity | 8 GB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| Discrete graphics card | No |
| On-board graphics card model | ARM Mali-400 |
| On-board graphics card | Yes |
| Network | |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi | Yes |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| S/PDIF out port | Yes |
| Combo headphone/mic port | Yes |
| Microphone in | No |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| HDMI version | 1.4b |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 3 |
| Performance | |
|---|---|
| Remotely operated | Yes |
| Housing material | Aluminium |
| Product colour | Black |
| Software | |
|---|---|
| Operating system installed | Android 5.1 |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 – 90% |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 0 – 50 °C |
| Certificates | |
|---|---|
| Certification | CE / FCC |
| Weight & dimensions | |
|---|---|
| Weight | 514 g |
| Height | 37.8 mm |
| Depth | 143.6 mm |
| Width | 154.2 mm |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
