TieDex UK Ubiquiti UniFi Switch USW-16-POE – switch – 16 ports – Managed – rack-mountable
Ubiquiti UniFi Switch USW-16-POE – Switch – Managed – 16 x 10/100/1000 (8 PoE+) + 2 x Gigabit SFP – rack-mountable, desktop – PoE+ (42 W)
Basic Specifications
- Manufacturer’s Part Number
- USW-16-POE
- EAN
- 0817882028547
- Manufacturer Warranty
- 1-year warranty
- Weight
- 2.8 kg
- Product Description
- Ubiquiti UniFi Switch USW-16-POE – switch – 16 ports – Managed – rack-mountable
- Model
- Ubiquiti UniFi Switch USW-16-POE
- Dimensions (WxDxH)
- 44.24 cm x 20 cm x 4.37 cm
- Features
- 12KV ESD Protector, fanless, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control
- Power
- AC 120/230 V (50/60 Hz)
- Device Type
- Switch – 16 ports – Managed
- Compliant Standards
- IEEE 802.3af, IEEE 802.3at, IEEE 802.11x
- Subtype
- Gigabit Ethernet
- Performance
- Non-blocking bandwidth: 18 Gbps ¦ Switching capacity: 36 Gbps ¦ Forwarding rate: 26.78 Mpps
- Enclosure Type
- Rack-mountable 1U
- Ports
- 16 x 10/100/1000 (8 PoE+) + 2 x Gigabit SFP
- PoE Budget
- 42 W
- Power Over Ethernet (PoE)
- PoE+
General
- Device Type
- Switch – 16 ports – Managed
- Enclosure Type
- Rack-mountable, desktop 1U
- Subtype
- Gigabit Ethernet
- Ports
- 16 x 10/100/1000 (8 PoE+) + 2 x Gigabit SFP
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 42 W
- Performance
- Non-blocking bandwidth: 18 Gbps ¦ Switching capacity: 36 Gbps ¦ Forwarding rate: 26.78 Mpps
- Authentication Method
- RADIUS
- Features
- 12KV ESD Protector, fanless, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control
- Compliant Standards
- IEEE 802.3af, IEEE 802.3at, IEEE 802.11x
- Status Indicators
- Status, PoE, link/activity/speed, link/activity
Dimensions & Weight
- Width
- 44.24 cm
- Depth
- 20 cm
- Height
- 4.37 cm
- Weight
- 2.8 kg
Miscellaneous
- Compliant Standards
- FCC, IC, ETSI 300 019-1-4
Manufacturer Warranty
- Service & Support
- Limited warranty – 1 year
Expansion / Connectivity
- Interfaces
- 8 x 1000Base-T RJ-45 PoE+ – 32 W ¦ 8 x 1000Base-T RJ-45 ¦ 2 x Gigabit LAN SFP ¦ 1 x management
Power
- Power Device
- Internal power supply
- Power Provided
- 60 Watt
- Voltage Required
- AC 120/230 V (50/60 Hz)
- Power Consumption Operational
- 18 Watt
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
